CHASSIS DRIVETRAIN SUSPENSION STEERING MORE SPECIFICATIONS To get up and running you will need: Item# C25311BLACKSILVERT3 Barcode: 91789019335
Extended ladder frame with alloy bracing
Anodized alloy skid plate
Anodized alloy battery plate
Anodized alloy front push bumper w/D-rings
Anodized alloy rear bumper w/D-rings
Anodized alloy adjustable side step rails
Anodized alloy transmission case with metal internals
Adjustable anodized alloy heatsink motor mount
Adjustable slipper clutch
Full ball bearing set
6x 1.9 anodized alloy beadlock wheels
6x 1.9 scale rock crawling tires
6x Universal drive axles
6x Anodized alloy hub carriers
6x Anodized alloy knuckles
3x Anodized alloy straight axle housings
3x Locked differentials with metal internals
3x Center HD drive shafts
Anodized alloy multi-link suspension
6x Anodized alloy oil-filled dampers
6x Two-stage shock springs
6x Anodized alloy threaded damper bodies
Adjustable shock mounting positions
6-Wheel steering configuration
6x Anodized alloy steering posts
3x Anodized alloy servo mount plate
3x Anodized alloy steering linkage
included electronic winch (mounted to front bumper)
Anodized alloy body mounts
Anodized alloy radio box
Velcro battery straps
length (w/bumpers): 25.78-inches (655mm)
Width: 9.05-inches (230mm)
Height: 5.9-inches (150mm)
Wheelbase (longest): 16.5-inches (419mm)
Weight (no batteries): 6.3 lbs. (2825g)
3-Channel Radio system with 3 servos and channel mixing (for 6WS)
2-Channel radio system with one servo (front axle steering only)
Heavy duty Electronic Speed Controller
2S-4S LiPo or 7.2-8.4 NiMH battery pack
Compatible charger
Batteries for the transmitter
Custom body
Experienced Installation Required
Integy products are designed for experienced RC enthusiasts. Unless included with the product itself, most of our products do not include instructions. The purchaser is responsible for any product assembly/disassembly, any set-up and adjustment, and periodic maintenance. If you need help disassembling your stock vehicle, you will need to refer to the instruction manual/exploded parts view of your particular vehicle, as provided by the manufacturer of your vehicle. If you are unable to assemble and/or install a product, please consult your local Integy dealer for assistance.
Assembly and Pre-installation Prep
All products will require some prep out of the package. Some items (shocks, gearboxes, axles, etc.) are assembled for packaging purposes only, and may require standard prep before installation and usage, such as shimming for proper alignment, checking tightness of all components and fasteners, installing your own shock oil, anti-seize, threadlock, or grease. Please be sure to apply threadlock on all metal-to-metal interfaces prior to installation; do not just install the item out of the package and assume they have been prepped correctly. Check, adjust, and set/reset all new items when taken out of the package. Some items may need final adjustment after installation.
Wheel and tire sets may be sold partially assembled for packaging purposes only and require standard wheel/tire prep before installation and usage. All wheels and tires require CA glue (if press-fit style) or separate assembly (if beadlock style) before being used. Wheels and tires are not always pre-glued from the factory (unless specified in the product name or description).
A Note About Hardware
Unless specified, not all products include hardware; if new or different-sized hardware and/or fasteners are included with the upgrade kit, those are meant to replace the factory hardware. Extra hardware, shims, or spacers may be required for some installations. Due to factory supply delays beyond our control, certain products may ship with hardware (screws, washers, etc.) that is different from what is originally shown in the website product photos. Any alternates will be compatible hardware that will not affect the functionality of the product.
1st/3rd-party Compatibility
Certain Integy-branded items replacing OEM parts may not be compatible with another Integy-branded items due to design language. Some parts may require permanent modification to the vehicle for fitment and may eliminate certain OEM features. Some items may require modification to the vehicle for proper clearance. Parts are for specified usage only. We do not guarantee compatibility with other aftermarket items.
What does "RTR" or "ARTR" Mean?
When a product is labelled RTR ("Ready To Run") it generally means that the vehicle chassis is assembled, and electronics are installed. You may still need some final items for operation (i.e. transmitter alkaline batteries, main battery pack and charger, paint for the body, etc.). When a product is labelled "ARTR" generally this means the same as "RTR" but without an included radio system and/or radio components. Please refer to the product description for additional details; no additional items are included unless specifically stated in the product description.
Product Photo Accuracy
Products show in photos may be updated at the production level and replaced by updated versions; we will always ship the most recent version to the customer. Colors shown in product photos are as close to possible to the actual item; color matching between parts is not guaranteed.
